Prehnite - The Epimorph Champion

Author: Vic Ridgley
Views: 591x

Prehnite is a common calcium silicate, which can form outstanding crystalline aggregates. Its nice crystal forms and pleasing colors make it a very popular among collectors. Prehnite is also used by jewelers and it is an important metamorphic index mineral.

Crystal Structure of Prehnite

Prehnite is a silicate of calcium and aluminum with the formula: Ca2Al(AlSi3O10)(OH)2. Limited Fe3+ substitution for aluminum is possible in the structure, other common impurities include Ti, Mg, Na and K. Prehnite belongs to the orthorhombic crystal system, and is composed of interlocking chains of silica tetrahedra in the Si:O ratio of 4:11.

Prehnite ball sitiing on the cluster of epidote crystals from Kayes region in Mali
Almost perfect prehnite ball sitting on dark epidote crystals from Kayes Region, Mali. Size: 7 x 5 cm. Collection and photo: Albert Russ

Crystallographic classification of prehnite is a little disputable. According to the Nickel-Strunz system, prehnite is an inosilicate. But according to Dana classification, prehnite is a phyllosilicate.

Its most distinctive features are its habit of finger-like growths, and its ability to encase another mineral undergoing dissolution and create thereby a hollow cast of the parent mineral.

Physical Properties of Prehnite

Prehnite occurs in many shades of green: light, mint, yellowish, brownish, bluish and dark. Less often, it is colorless, blue, pink, or white. Pure prehnite is colorless; its colored varieties are caused by impurities in the structure. Green color is caused by the presence of Fe3+.

Ball made of tin prehnite crystals from Obri dul in Czech Republic
Typical prehnite ball from Obri dul, Czech Republic. Size: 6 x 8 mm. Collection and photo: Vitezslav Snasel

It most often forms as botryoidal aggregates, with only just the tops of small curved or composite crystals showing any faces. Crystals may also be curved, wedge-shaped, stalactitic, globular or reniform. Bubbly crystal masses may develop into epimorphs (hollow casts) of anhydrite, glauberite, or laumontite.

Prehnite is translucent, not pleochroic, and mildly fluorescent in blue (short wavelength UV) and in yellow (long wavelength UV). Cleavage is good on {001} and poor on {110}. Its luster is vitreous to waxy to pearly. Its fracture is uneven and brittle. Its hardness is 6.0-6.5, its streak white to colorless, and its density is 2.80-2.95.

Prehnite might look very similar to aragonite, hemimorphite or smithsonite. However, it does not occur in the same places as hemimorphite or smithsonite. Aragonite is much softer and reacts with hydrochloric acid (HCl).

Naming and Discovery

Colonel Hendrik von Prehn (1733-1785), military commander at the Dutch colony at the Cape of Good Hope, South Africa is credited with the discovery of the mineral in 1774 in his rambles among the Karoo dolerites of the Eastern Cape Province. He brought the first specimens to Europe. Through unexplained circumstances, the renowned German geologist, Abraham Gotttlob Werner, came to name the mineral prehnite in 1788, in honor of the Colonel.

Detail of alpine vein with green prehnite, olive green clinozoisite, pink laumontite and white calcite from Markovice quarry in Czech Republic
Pale green prehnite - associated with calcite, laumontite and green clinozoisite - from Markovice, Czech Republic. Size: 5 x 3.5 cm. Collection and photo: Zbynek Burival

Prehnite carries the twin distinction of (allegedly) being the first mineral named in honor of an individual, and of provoking the first essay (Richard Chenevix, 1813) denouncing the practice!

Historical Names

Owing to confusion with other silicate minerals, prehnite was also called chrysotile, Cape Emerald, adelite, aedelite, chiltonite, coupholite, faux-zeolite, anchi-zeolite, as well as cognates prehnit and prehnita.

Varietal names

  • Prehnite Fingers are elongate forms in general.
  • Snakehead is an elongate prehnite epimorph with a widened head.
  • Roman Helmet is a hemispherical ball with a protruding central rounded arc.

Origin

Prehnite is a common calcareous aluminosilicate mineral occurring in two typical environments, either as a low-temperature alteration product found in cavities and veins of volcanic rocks, or as a low-temperature index mineral in the lowest member of conventionally-described metamorphic facies sequences (prehnite-pumpellyite; greenschist; amphibolite; granulite).

Perfect apophyllite crystal sitting on prehnite matrix from Poona in India
Prehnite and apophyllite from Poona, India. Size: 8 x 8 mm. Collection and photo: Vitezslav Snasel

Prehnite is often found associated with zeolites in veins or cavities of basaltic rocks. Zeolites, of which there are dozens, are microporous aluminosilicate minerals usually produced by weathering or hydrothermal alteration of both silica-rich and silica-poor volcanic rocks.

The other typical environment for prehnite is Alpine-type veins. Prehnite usually occurs in calcium-rich rocks like amphibolites, often associated with laumontite, axinite, titanite, epidote, clinozoisite and calcite.

Applications

Prehnite is prized as a collectible and used as a minor gemstone; dealers are known to enhance its luster by adding oils to the surface. Historically, prehnite is known from China as a polished ornamental stone, also used for inlay work.

Alpine vein filled with prehnite and apophyllte crystals from Libodrice quarry in Czech Republic
Green prehnite with white apophyllite from Libodrice, Czech Republic. Size: 7 x 4.5 cm. Collection and photo: Zbynek Burival

Occurrence of Prehnite

The best endowments of prehnite appear to occur in selected areas of Canada, the United States, Africa, Australia, India and China.

A unique form of prehnite was found in the Jeffrey Quarry in Asbestos, Quebec, Canada, as large, individual and flattened dipyramidal crystals and clusters.

In the U.S., the occurrences are mostly related to both basalt quarries and the lower-grade metamorphic terrains of the northern Appalachians, in New Jersey in particular as well as Connecticut and Massachusetts.

Botryoidal aggregates of pale green prehnite crystas from Djebel Mehl in Morocco
Prehnite from Djebel Mehl, Morocco. Size: 10 x 6.5 cm. Photo: Albert Russ

Northwestern New Jersey provides superb examples of fingers, snakeheads and botryoidal, hemispherical blobs in the Upper and Lower New Street Quarries and in Prospect Park, Passaic County; yellowish rounded balls were found in the Millington Quarry, Somerset County; and triangular clusters of exceptional epimorph glauberite casts came from Fanwood, Somerset County.

Multiple basalt quarries in Connecticut are repositories of high-quality prehnite: the O & G Quarry in Southbury, New Haven County (including rare white prehnite); the O & G Quarry in Woodbury, Litchfield County; and the Roncari quarry, East Granby, Hartford County. In Massachusetts, the Lane Quarry, Hampden County contains prehnite associated with sharp black babingtonite. Further south, the Foote Minerals Lithium (pegmatite) Mine in Cleveland County, North Carolina provides unique tabular green crystals.

Alpine vein with apple green prehnite crystals from Markovice quarry in Czech Republic
Typical prehnite aggregate from Markovice, Czech Republic. Size: 7 x 4 cm. Collection and photo: Zbynek Burival

Africa hosts several outstanding sources of prehnite in Mali, Tanzania, Namibia and South Africa. The most developed deposits are in the Kayes Region of Mali, where the prehnite occurs as perfect thick formations associated with dark epidote. Specific Kayes occurrences include Djouga (Bendoukou), Diakon, Sandare, and Sadiola.

The Merelani Hills in Tanzania provide highly transparent prehnite. The Goboseb Mountains, Brandberg District, Namibia supply mint green prehnite. The Kalahari Manganese Fields of South Africa, at the N'Chwaning Mines in Kuruman, yield an bright orange acicular crystals, an extremely odd and different form of prehnite.

The principal Australian occurrences are at the basalt tableland surrounding Wave Hill Station in the central Northern Territory and the Prospect and Mullaley areas of New South Wales.

Perfect pale green prehnite balls sitting on the epidote crystal from Kayes region in Mali
Nice prehnite balls with dark epidote crystals from Kayes region, Mali. Size: 6 x 5 cm. Collection: Alfred Schreilechner, photo: Albert Russ

The Kandivali Quarry, Mumbai, India is the home of large and exceptionally delicate masses of prehnite epimorphs after laumontite. In China, Qiaojia (Yunnan Province) and the Hongquizhen Quarry, Meigu (Sichuan Province) have supplied several new deposits of gem-quality prehnite.

Some notable occurrences of prehnite are to be found in Europe too, in particular the Oficarsa Quarry, Carchelejo, Spain and Bourg d'Oisans, Isère, France. Nice prehnites are known from many Alpine type veins, mostly in amphibolites from Austria and Czech Republic.
